Tally T6090 - Page 152

B-18
Maintenance Manual
Component # Description Part Number C9 Capacitor 47Mfd 25V ALUM 731706 C12 C23 C35 Capacitor 120Pfd 50V ±10% 730168 C13 C15 C20 C33 C34 C36 C41 C43 C44A C44 C46 C47 C49 C52 C53 C58 C59
Capacitor .1Mfd 50V 730142
C24 C26 C31 Capacitor 10Pfd 50V ±10% 730334 C28 Not Installed C4 C5 C30 Capacitor 22Pfd 50V ±10% 730195
C10 C32 Capacitor .01Mfd 50V ±10% 730196 C37 C38 C39 Capacitor 1200Pfd 100V ±10% 402910 – 126 C40 C47 Capacitor 470Pfd 50V ±10% 402910 – 730194 C6 C14 C45 C51 C54 Capacitor 1000Pfd 50V ±10% 731017 C3 C11 C48 C56 C57
Capacitor 120Pfd 50V ±10% 730168
C50 C15A C15B Capacitor 10Mfd 25V 4730442 C55 Capacitor .33Mfd 50V 730119 CR1 CR2 Diode 1N914B 400836 – 04
Y1 Crystal 20MHz Par. Fund 731707 Y2 Crystal 3.6864MHz Par. Fund 731242 Y3 Crystal 32.768KHz 731096 Q1 Transistor 2N3904 401340 – 01 Q2 Transistor 2N4403 731690
L1 L2 Leaded Ferrite Bead 730098 L3 L4 Leaded Ferrite Bead 730098 LED3 LED 731735 DS1 Sparkgap 7312705 J3 8 Pin Phone Connector 403760 – 03
J4 BNC Connector 731701 J14 39 Pin Connector 730385 J15 25 Pin Connector 730147 J17 32 Pin Female DIN Connector 404-94 – 731734 U1 I.C. DP8392CV 731698
U2 I.C. DP83934CVUL – 25 731699 U6 I.C. MC68340 731064 U12 Firmware I.C. 28F400 081191 U11 U13 I.C. 28F200 731121 U14 DRAM I.C. 514256 731519
Component # Description Part Number U15 U16 I.C. 74F158 731513
C21 C25 C27 C29 Capacitor .01Mfd ±10% SMD 731545 R14A R208 Resistor 47Ω 1/4W ±1% SMD 731546 T1 Filter Module SF1020 731704 T2 Pulse Transformer ST7033 731703 VR1 Voltage Regulator PM6535 731702
