B-22
Maintenance Manual
Component # Description Part Number
Y2 Crystal 3.686MHz PAR FUND 404050 – 731242
Y3 Crystal 32.768MHz 404012 – 731096
VR1 Voltage Regulator 7905 401444 – 02
Q1 Transistor 2N4403 400709 – 730098
Q2 Transistor 2N3904 401340 – 01
L1 L2 Leaded Ferrite Bead 403747 – 730098
T1 Transformer PF5769 403845 – 730850
J14 36 Pin Connector 403967 – 730385
J15 25 Pin Connector 403081 – 730147
J17 32 Pin Female DIN Connector 404094 – 731734
J204 15 Pin Connector 403941 – 730166
