Chapter 3: Troubleshooting
3–7
Table 3–1, Continued
MESSAGE Explanation and Corrective Action
Print Fault
Explanation
: Faulty communication between the main and control processor has
occurred causing a dot row to misprint. The printer automatically
recovers from this condition.
Corrective Action
: Under normal circumstances there is no corrective action other than to
depress the CLEAR Key to remove the fault message from the
display. If this does not clear the problem, remove and replace the
Personality CBA. If, however, this problem persists, remove and
replace the Engine Controller CBA.
RAM Test Fail
Explanation:
A fault has been detected in the Main Processor primary RAM or a
fault exists in the RAM address lines.
Corrective Action:
Remove and replace the Personality Module CBA.
Self Testing
Explanation:
The printer is performing internal diagnostic tests.
Corrective Action:
If this message does not clear automatically after a few seconds,
remove and replace the Personality Module CBA.
Setup Address
Explanation:
The printer address has not been set up or a configuration with
address set to UNDEFIN has been loaded.
Corrective Action:
Set up the printer address using the multilevel menus on the printer.
The procedure is located in Chapter 4 of the Operator Manual, under
the Configuration Menu.
