GTS Technical Manual
26. March 2013 Edition: V2.00/2013 5-22
Copyright © 2013, Diversey Inc.
05.11.15 guide bar - articulation old setup - 350B_V1.00.fm
Ensure the O-ring (02/107) is placed correctly.
• Mount sustaining disc.
Ensure the O-ring (02/107) is placed correctly.
• Position the three screws and tighten them.
Adjustment
Tighten the screws with 20 Nm.
• Position the end bolt of the bowden cable at the lock (02/110) of
the handle position.
Ensure that the lock of handle position is nicely fitting into toothed
wheel (02/108).
• Position spring downwards to the lock of handle position.
• Position bowden cable into articulation.
• Complete assembling according to chapter ADJUSTING OF
BOWDEN CABLE HANDLE ADJUSTMENT.
