GTS Technical Manual
26. March 2013 Edition: V2.00/2013 5-26
Copyright © 2013, Diversey Inc.
05.40.14 squeegee - front blade - 350B_350E_V1.00.fm
5.3 Squeegee
5.3.2 Mounting of front blade
Picture 40: Front blade fixation
• Position new front blade onto the pins of squeegee inlet.
• Mount the squeegee inlet into squeegee body.
• Tighten the two handles.
Ensure that the blade is mounted correctly and the squeegee inlet fits
into the squeegee body.
