GTS Technical Manual
26. March 2013 Edition: V2.00/2013 5-49
Copyright © 2013, Diversey Inc.
05.58.17 brush & motor - wiping blade - 350B_V1.00.fm
5.7 Brush & Motor
5.7.9 Mounting of wiping blade
Picture 65: Wiping blade
• Position new wiping blade onto the pins.
Ensure that the blade is mounted correctly.
• Position cover for wiping blade and snap it on.
Picture 66: Mount wiping blade
Ensure that the cover for the wiping blade is mounted correctly.
