GTS Technical Manual
26. March 2013 Edition: V2.00/2013 6-15
Copyright © 2013, Diversey Inc.
06.20.10 charger - 350B_V1.00.fm
6.4 Charger
6.4.2 Mounting of charger
Picture 11: Charger
• Mount the connection block with screw.
• Connect the wires and the communication plug.
•Mount the charger.
• Position battery cover.
• Mount the 4 screws for battery cover.
