GTS Technical Manual
26. March 2013 Edition: V1.10/2013 6-1
Copyright © 2013, Diversey Inc.
06.10.10 system architecture - 350B_455B_V1.00.fm
6.1 System architect
6.1.1 General
Remarks
The following instructions are for TASKI swingo 350B/455B as they
have the same electronics.
• The firmware is memorised only on the power electronics.
• The foil keyboard visualises the states of the machine. It also
functions as a connection between the power electronics and the
devices (e.g. vacuum motor and pump).
• Applying the correct torque where required is essential for a safe
operation of the machine.
• ESD can harm the electronic boards and therefore reduce the life
time of the machine. Use always an ESD bag to protect them.
6.1.2 System overview
Picture 1: System overview 350B
