GTS Technical Manual
26. March 2013 Edition: V2.00/2013 5-25
Copyright © 2013, Diversey Inc.
05.40.14 squeegee - front blade - 350B_350E_V1.00.fm
5.3 Squeegee
5.3.1 Removing of front blade
Picture 38: Squeegee front side
• Remove the two handles, star knobs (03/102).
• Press out the squeegee inlet (03/112).
• Remove the front blade (03/117) by tearing it off of the
squeegee inlet.
Picture 39: Front blade fixation
