GTS Technical Manual
26. March 2013 Edition: V2.00/2013 5-42
Copyright © 2013, Diversey Inc.
05.58.10 brush & motor - brush motor belt - 350B_V1.00.fm
5.7 Brush & Motor
5.7.2 Mounting of brush motor belt
• Mount the brush motor belt.
• Tension the belt by lifting up the brush motor.
Remarks
You can lift up the brush motor with a screw driver. Place the screw
driver from the front side into the 12mm hole of the bracket (08/105).
• Tighten the brush motor fixation screws.
•Mount the belt cover.
Ensure that the brush cover is positioned correctly as it has also the
function to prevent water to get inside.
• Mount the brush cover screw.
• Position the recovery tank.
• Position the cover complete.
