GTS Technical Manual
26. March 2013 Edition: V2.00/2013 5-50
Copyright © 2013, Diversey Inc.
05.60.10 filter - filter - 350B_350E_V1.00.fm
5.8 Filter
5.8.1 Removing of filter
Picture 67: Filter
• Remove clear water tank assembly according to chapter
REMOVING OF CLEAR WATER TANK ASSEMBLY.
Ensure that no water is in the fresh water system before you
disconnect the hoses.
• Remove filter cover (09/102) of filter.
• Remove fixation screws from chassis.
Picture 68: Remove filter
• Disconnect the fresh water hoses (09/120&128).
• Thread out filter from the chassis (05/109).
• Remove complete filter.
