GTS Technical Manual
26. March 2013 Edition: V2.00/2013 6-12
Copyright © 2013, Diversey Inc.
06.18.27 electronics - connections - 350B_455B_V1.01.fm
Pos. Plug Description [plug] Pin Description [pin]
1 GND GND 1 GND
2 SM Vacuum motor 1 Vacuum motor
3 BM Brush motor 1 Brush motor
4+24+24VDC 1+24VDC
5 DV Dosing valve 1 350B: Not used / 455B: Filter +24VDC
5 DP Dosing pump 1 350B: Pump / 455B: Not used
6 BMS Charger communication 1 Charge (yellow)
6 BMS Charger communication 2 Charged (green)
6 BMS Charger communication 3 Failure (red)
6 BMS Charger communication 4 Immobiliser
6 BMS Charger communication 5 Immobiliser
6 BMS Charger communication 6 GND
7 Foot SW Foot switch 1 350B: Not used / 455B: Bridge
7 Foot SW Foot switch 1 350B: Not used / 455B: Bridge
7 Foot SW Foot switch 1 350B: Not used / 455B: Foot switch
7 Foot SW Foot switch 1 350B: Not used / 455B: Foot switch
7 Foot SW Foot switch 1 Not used
7 Foot SW Foot switch 1 Not used
8 Dashboard Ribbon cable Refer to chapter DASHBOARD CONNECTIONS
Table 2: Electronic connector description
