ATTENTION: NOTE THE
CORRECT POSITION OF THE
SPRING WASHERS.
Remove the friction rings on the brack-
et support for revolving display, (TOOL:
slotted screwdriver).
During the reassembly procedure, use
white lubricating grease for the friction
rings.
TECHNOGYM BIKE LIVE Technical Service Guide
Rev. 2.0
- 84 - TSG-00187-EN - Uncontrolled copy if printed
