6. TROUBLESHOOTING & CONFIGURATION
To correctly perform the troubleshooting operations, the following is required: Laptop, USB- Micro
USB cable.
6.1 PROCEDURE TO FOLLOW WHEN REPLACING
COMPONENTS
6.1.1 
When replacing the display:
1. With a USB-MICRO USB cable, connect the equipment to the laptop
2.Update the SW to the latest released version. For details, refer to §”5.1 SW UPDATE (VIA PC
USING THE USB-MICRO USB CABLE)”
If necessary, write the machine serial number and set the correct machine type by pressing
“CHANGE MACHINE TYPE” button on Equipment Software Loader.
6.1.2 
When replacing the Brake Board:
1. With a USB-MICRO USB cable, connect the equipment to the laptop.
2. Update the FW to the latest released version. For details, refer to §”5.1 SW UPDATE (VIA PC
USING THE USB-MICRO USB CABLE)”
6.2 EQUIPMENT TESTING AFTER THE
INTERVENTION OF TECHNICAL SERVICE
After a technical service intervention, the technician MUST check - in the same conditions in which
the customer discovered the problem - that the fault has been resolved.
The technician MUST also perform the following standard operating tests:
• Check that the equipment is stable on a at surface;
• Switch on the equipment and start an exercise:
- Pedal and check that the speed indicator varies;
- Check that the hardness of the exercise and the level of di󰀩culty varies when you
press the lever of the di󰀩culty level ;
• Check the presence / the state of wear of warning labels. Check if the warning labels ar-
ereadable.
• Check the correct reception of the signal transmitted by heart rate monitors
