6.5 NO RESISTANCE FEELING DURING EXERCISE
No resistance feeling during exercise
Start to pedal. Are the Watt and RPM
different from 0?
NO
YES
Is the brake board working [1]?
YES
Check the continuity of the
cable 0WCU1149xx that connect
the brake board to the brake.
Is there continuity? [2]
NO YES
Check the brake. [3]
If necessary,replace the brake.
[*] [**]
Replace the cable that
connects the brake board
to the brake. [*]
Check the RPM sensor.
Is it working? [4]
NO
YES
Replace the brake
board [*][**]
Check the continuity of the cable
that connects the brake board
to the RPM sensor.
Is there continuity? [5]
NO
YES
Replace the RPM sensor
[*] [**].
NO
Replace the cable that
connects the brake board
to the RPM sensor.[*]
Replace the brake board [*] [**].
Fig. 20
[*]: Make sure the problem is solved. See paragraph “6.2 Equipment testing after the intervention
of technical service”
[**]: When replacing components see the paragraph “6.1 Procedure to follow when replacing com-
ponents”
[1]: Put the probes of the tester in the PIN 1 (inductive brake + - white) and PIN 2 (inductive brake
- - grey) of the 3x2 pin connector, connected to the brake board, coming from the electromagnetic
brake. Start to pedal and increase the di󰀩culty level. Set Vdc in the tester, higher is the di󰀩culty
level selected higher must be the Vdc measured.
