6.8 THE DISPLAY DOES NOT TURN ON
After a few seconds of inactivity (e.g. 60 sec), the equipment goes into sleep mode, then the
display turns o.
The display does not turn on
Vibrate the equipment. Does the accelerometer function?
OK. The machine works.
Turn on the equipment. Does the display
turn on?
YESNO
YES
Replace the display[*] [**]
Do the external fuses function?
NO
YES
Replace the fuses and try again.
[*] [**]
NO
Check the power supply cable of the equipment.
Does it function? [1]
Does the brake board supply 12Vdc
to the display? [2]
YES
NO
Replace the cable. [*] [**]
Turn on the equipment. Is the
LED on the brake board lit?
YES
NO
Does the power cable supply
110/220 Vac to the brake board?[3]
YES
Replace the brake
board. [*] [**]
NO
Replace the cable.
[*] [**]
YES
Are 12Vdc present at the input of the
display? [4]
Replace the brake
board. [*] [**]
NO
YES
Replace the display
[*] [**]
NO
Check the continuity of the cable.
If necessary, replace it. [*] [**]
Fig. 30
[*] Make sure the problem is solved. See paragraph:”6.2 Equipment testing after the intervention
of technical service”
[**] When replacing components see the paragraph “6.1 Procedure to follow when replacing com-
ponents”.
[1]: Disconnect the power supply cable of the equipment and insert the tips of the tester between
Phase and Neutral. You must measure 110/220Vac.
