6.7 WRONG SPEED SIGNAL
Wrong speed during exercise
Update the fw of the brake board. Upload the brake table.
Is the problem solved?
OK. Problem solved.
Are the detection screws present and/or
assembled in the right way? [1]
YESNO
YES
Check the RPM sensor position
/ replace the RPM sensor. [*] [**]
Reassemble the screws in the right
way. [*]
NO
Fig. 29
[*]: Make sure the problem is solved. See paragraph: “6.2 Equipment testing after the intervention
of technical service”
[**]: When replacing components see the paragraph “6.1 Procedure to follow when replacing com-
ponents”.
[1]: The distance between the speed sensor and the closest screw of the copper disk (making a
complete rotation of the disk using a thickness gauge) must be: d = 0.8 ÷ 1.0 mm.
TECHNOGYM ELLIPTICAL Technical Service Guide
Rev. 1.1
- 54 -
