Technogym ELLIPTICAL - Disassembling the Locking;Unlocking System

86
Unscrew clockwise the pulley [86] of
the ywheel.
87
Remove the ywheel [87]
7.18 
SYSTEM
Remove all the necessary front casings as described in §”7.9 DISASSEMBLING THE FRONT
CASINGS”
88
Remove the interlocked casing [88].
TECHNOGYM ELLIPTICAL Technical Service Guide
Rev. 1.1
- 119 -
Uncontrolled copy if printed
