Technogym ELLIPTICAL - Structure for Entering Commands

▪ Select Baud rate 19200;
▪ Click DTR;
▪ Click Connect, to the top left and verify that the CTS button has turned green;
▪ The commands can now be entered, writing the string in the provided area.
Fig. 19
6.4.1 STRUCTURE FOR ENTERING COMMANDS
The structure of the command/message is: @COMMAND [ARG1] [ARG2]# where:
Character  
@ YES Message start marker.
COMMAND YES Command. The acceptable commands are de-
scribed in the following sections
ARG1 NO First Topic of the command (if required by the
command).
ARG2 NO Second Topic of the command (if required by the
command).
#
(hash)
YES Message end marker
Tab. 12
