42
Remove the circlip [42]. (TOOL: slot-
ted screwdriver/ circlip pliers)
43
Turn the pedal upside down and loos-
en the nut [43]. (TOOL: 8mm combi-
nation wrench, open and oset ring
ends)
Then remove the cable from the lever.
TECHNOGYM ELLIPTICAL Technical Service Guide
Rev. 1.1
- 84 -
