53
Unhook the special screw [53].
(TOOL: 8mm hexagon key wrench)
54
It’s now possible to remove the lever
[54]. (TOOL: soft-faced hammer)
  DURING THE
REASSEMBLY PROCE-
  
AFOREMENTIONED IN-
STRUCTIONS IN THE RE-
VERSE ORDER. THEN
ADJUST THE DISTANCE
   -
AL CUT AND THE REAR
FOOT CASING ON THE
BASIS OF THE MEASURE-
MENT TAKEN BEFORE
DISASSEMBLY. THE DIS-
   

MEASURING TAPE)
