Stylus height and ±: values allowing the use of the stylus watch. Height must be between
1 to 9mm and the delta between 0.5 and 2.5mm. More information about this feature in
maintenance chapter.
D axis : allows configuring the use of optional D axis for the file.
D axis Accessory must be activated beforehand in accessories
There are 3 possible options for D axis:
o None : marking is made without D axis
o Circumference: The marking is made on the part circumference.
o Generator: The marking is done in x y, so flat.
For more information about D Axis option use, see D Axis.
Z Sensor: Allows configuring the use of optional Z sensor axis for the file.
When using Z sensor axis, you must enter the distance (height) where the marking head
should be positioned. This distance is the distance stylus-part.
Z axis must have been previously activated in accessories
Z Electric: Allows configuring the use of optional Z electric axis for the file.
When using Z electric axis, you must enter the course (distance between the high machine
position and the end of the move). The machine will go down of the entered value and start
marking.
Z axis must have been previously activated in accessories
Mark & close : if this function is active, the current marking file is closed after marking
preventing from an unexpected double marking of the same file. A new empty file is created
and if automatic backup is enabled the file is saved before closing it.
