After charge, internal control box temperature can be high. Let the temperature fall before
starting new marking. In fact, a heavy duty of the marking machine using the battery will increase the
battery temperature and make the control box under temperature security.
In average or high sleep mode, the battery does not recharge.
Information about battery state is available through icons in the status bar
No battery detected
battery full
battery middle
battery empty
battery charging empty
battery charging middle
battery charging full
c) External Charger (Optional)
The external charger characteristics are:
Power supply : 110-115 V AC or 220-240 V AC
Usable temperature : 32°F to 115°F ( 0°C to 45 °C)
Quick charge current : 1 A
The quick charge time is around 2:30h. There are 2 indicator lights on the charger, showing when the
charger is under tension (LED AC On) and when the battery is fully loaded (Charge OFF)
As soon as the CHARGE OFF Light is on your battery is ready for use.
G. Carte 8E/S (Optional)
An additional card is available as an option to use additional inputs/outputs.
See Interfacing instruction for Multi4 Control Unit dedicated document for more information.
