When the IDI function is activated, the machine makes a test impact to evaluate the distance and
adjust the force used to correspond to what is asked for.
IDI function is available in two different modes:
Flat mode: The test impact is done at each beginning of line. This is ideal for flat shapes, with
little slope.
Note: Ideal to have the same hitting depth on the part, without worrying about the distance.
Curved mode: The test impact is done at each beginning of character. This mode allows a
constant depth when marking on cylinders, corrugated parts, …
Note: Ideal to mark parts with a constant depth when they present an uneven distance along
the length of the marking.
Marking with IDI curved mode and without IDI
The IDI mode is displayed on the main screen with the following icons:
IDI deactivated
IDI flat
IDI curved
c) Setting height and width
Pressing on Set Height and Width allows using the position arrows to change height and compression
of the current line.
Setting the height the minimum value is 0.4mm, the maximum value 200mm and, steps vary from
0.2mm to 1.6mm.Setting the compression the minimum value is 50%, the maximum value 150% and
steps vary from 5% to 40%.
The key stays in the pressed state during the modification:
The Up and Down position arrows allow increasing and decreasing the height. As the width is
dependant from the height, it will vary proportionally.
The left and right position arrows allow increasing and decreasing compression. Compression is used
to deform characters and modify the width, without changing the height.
