The new marking lines are automatically centred on the generator. Nevertheless you can displace
them in the usual way.
In Circumference mode, the view depends on the part to be marked diameter. If the circumference is
less than the marking window, the view is reduced to the circumference development of the part to
be marked.
If the circumference is more than the marking window, the view is set at the marking window
scale .You can then scroll the circumference using a combination shift + position arrow, up or down.
In circumference mode, even if the marking will be done on all the part circumference, the
error marking outside the window could appear. You should then position properly your marking in
the graphical view.
Circumference mode example
If not already done, first associate the D axis accessory depending on your model.
