The navigation inside the window is done with the up and down position arrows. The right and left
position arrows allow modifying the values.
3
rd
Axis: You can select (in the accessory list) the one connected to the third axis of your
marking machine.
4
th
axis: If you have the forth axis option, you can select in the accessory list the one
connected to the forth axis of your marking machine.
Other : Allow to choose to use an accessory without additional axis
Accessories are configurable with Accessories Parameters, if they have been selected:
D Axis- D Axis Max: you can modify Y offset of the D axis position. It corresponds to the D
Axis position related to the marking window. More information in D Axis
Z Sensor and Z Electric: You can modify the maximum course corresponding to the physical
column dimension. More information in Z Axis Sensor or Z Axis Electric
Plate feeder: You can redefine the marking, bolting and evacuation positions, depending on
the plate type used. More info at Plate feeder
Z Tor : No parameter
Use to confirm your modifications or use to cancel your modifications.
When confirming, the program restarts automatically to take the accessory modifications into
account.
Advanced
Advanced allows the user to configure the marking machine advanced parameters with the following
window:
