a) Installing or replacing the battery
b) Operating
MULTI4 is charging the battery when the machine is connected to the mains power and ON, the
charging function of the control box is automatically charging your battery whatever it's level of
charging and is trickling it as soon as the battery is full. We offer as well a specific external charger.
If you work on mains and wish to toggle to battery supply without shutting off the machine,
commute the power switch to 0. A window will appear asking if the user wishes to shut down the
machine or not.
If you answer yes the machine shuts down. If the answer is no or no answer after 2 seconds, the
machine toggles to battery mode.
The charge mode is fully automatic. The battery will charge as soon as needed. The charge is
completed in 2:30 h
The battery key allows to switch off the machine when it is working in battery mode, or to
switch on if needed.
When in battery mode, LED: will flash every two second.
To install the battery pack please
follow the next steps:
unscrew the M4 screw (rep 1)
Remove the battery cover
Keep the control at a vertical
position
Place the battery in the cover as
show on the picture (A)
Connect the battery to the
connector inside the control box (B)
Place one side of the cover in the
locating on the control box (C)
Slowly close the cover without
hurting the wires between the cover
and the control box (D)
Screw the cover using the rep 1
screw
