TRAÇABILITÉ CRÉATIVE
CREATIVE TRACEABILITY
TECHNOMARK
1 Allée du développement 73
42350 La Talaudière (France)
Tel : +33 (0) 4 77 22 25 91
Fax : + 33 (0) 4 77 22 38 93
E-mail : info@technomark-marking.com
V : SJ Le : 20/06/17 R : DD
www.technomark-marking.com
2 Marking machine mechanical components view (except Multi4 mini)
3 Stylus assembly open view
Hand nut
Stylus guide
Return spring
Stylus
Core
Guiding rod
Pin assembly
Guiding rail
Guiding wheel
Spline shaft
Translation screw
