Trigger Setup and Run
B1 (I2C)
4. Push and keep pushing the Source Bus
button of the lower-bezel menu until you se lec t
the bus that you want to trigger on .
B2 (I2C)
5. Push and keep pushing the lower-bezel menu
Trigger On button until you select the desired
trigger on feature.
IfyouareusingtheI
2
C bus trigger, you can
trigger on St art, Repeated Start, Stop, Missing
Ack, Address, Data, or Address/Data.
If you are using the SPI bus trigg er, you can
trigger on SS Active, MOSI, MISO, or MOSI
&MISO.
If you are using the CAN bus trigger, you can
trigger on Start of Frame, Type of Frame,
Identifier, Data, Id & Data, End of Frame, and
Missing Ack.
104 DPO4000 Series User Manual
