Tektronix DPO4000 Series User Manual

Application Examples
2. Push Select Measurement.
Select
Measure-
ment
a1
Remove
Measure-
ment
Gating
Off
Statistics
Off
Reference
Levels
Indicators
Configure
Cursors
3. Turn multipurpose knob a to select channel 1.
This step is only needed if you are acquiring
data on more chan nels than just channel 1.
4. Select the Rise Time measurement from the
side-bezel menu.
Rise Time
DPO4000 Series User Manual 211
