Application E xamp les
5. Press Reference Levels.
Reference
Levels
6. Push Set Levels in to select units.
Set Levels
in
%units
7. Push High Ref and turn multipurpose knob a
to enter 2.00 V. If needed, push Fine to change
the sensitivity of the multipurpose knob.
High Ref
a2.00V
Mid Ref
8. Push Low Ref and turn multipurpose knob a to
enter 800 mV. If needed, p ush Fine to change
the sensitivity of the multipurp ose knob.
Low Ref
a800mV
