Appendix A: Specifications
Table 13: Displ
ay system
Characteristic Description
Interpolation
Sin (x)/x
Waveform styles
Dots, vectors
Persistence
Off,1s,2s,5s,infinite
Format YT or XY
Table 14: Courseware software: minimum requirements needed to install the Courseware software
Characteristic Description
Operating System Windows XP, Windows 7, Windows 8, Linux (Ubantu 12.04, 12.10, 13.04 or Fedora 18, 19)
RAM
512 Megabytes (MB)
Disk space
1 Gigabyte of available hard disk space
Display
XVGA 1024 * 768 with 120 dpi font size recommended
Removable media
CD-ROM or EVE drive
Peripherals
Keyboard and Microsoft mouse or other compatible pointing device
Table 15: Physical characteristics
mm inches
Height 158.0 6.22
Width 326.3 12.85
Dimensions
Depth 124.2 4.89
mm
inches
Height 266.7 10.5
Width 476.2 18.75
Shipping dimensions
Depth 228.6 9.0
kg lb.
Instrument only 2.0 4.4Weight
Instrument with accessories 2.2 4.9
mm
inches
Width 482.6 19.0
Height 177.8 7.0
RM2000B rackmount
Depth 108.0 4.25
Table 16: Environmental
Characteristic Description
Temperature
Operating: 0 to +50 °C
Non-operating: –40 to +71 °C
Humidity
Operating and non-operating:
Up to 85% relative humidity (RH) at or below +40 °C
Up to 45% RH at or below +50 °C
Altitude
Operating and non-operating:
Up to 3,000 m (9,843 feet)
112 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual
