Telephone Line Emulator User’s Manual
40-400-00020, Rev. M
5
Setting up the TLE
Power up the TLE
The TLE uses a universal power supply that operates from 100-240 VAC, 50/60 Hz.
Connect AC power to the TLE, then turn the rear panel power switch to the ON position.
Grounding is assured by using the appropriate (approved) power cord.
The green Status LED on the front panel will indicate the state of the system. The LED
should blink between mid-to-full brightness. If the LED fails to light, disconnect power
immediately and contact Teltone Technical Support at 425-951-3390.
Adequate air flow must be maintained in order for the unit to operate correctly. Do not
wrap the unit in blankets, paper, or other material that may impede ventilation.
Installing the TLE Configuration Software
The TLE Serial Port uses a standard RS-232 DCE interface. Using the cable provided,
connect the TLE to a personal computer running a Windows-based operating system.
(Optional with PC-software V2.00 or greater.)
Windows 95 or Later Versions
1. Insert the CD-Rom into the drive.
If the installation automatically starts, skip to step 4.
2. On the TaskBar, left click START, then RUN.
3. Type in your drive designator, followed by Setup.exe
example: r:\setup.exe
4. Follow the instructions on the screen to complete the installation.
5. Confirm that the correct communications port is configured. PC-Software V2.00 and
greater will automatically display the TLE-Comm Port selection screen if the TLE is not
connected or uses a port other that Comm1. Select the appropriate port and then
D
etect. The TLE software will test to see if your TLE is connected. The control leads
status are shown at the bottom of the window. If the TLE is connected with the proper
cable; all should be green. If not; CTS, DSR, and CD are normally red. Select Cancel
if your TLE is not connected at this time. Select OK to complete the CommPort
selection.
