Telephone Line Emulator User’s Manual
40-400-00020, Rev. M 106
Revision History
Version 1.00 TLE-Base - Initial Release
TLE_PC.EXE 09/23/97
TLE_PC V1.00
BIOS V1.00
DSP V1.00
MCU V1.00
Version 1.01
TLE-ADV - Advanced Simulation Module Release
TLE_PC.EXE 10/10/97
TLE_PC V1.01
BIOS V1.00
DSP V1.00
MCU V1.01
Changes: Networked Operating Systems Win95 and WinNT use a copy of
MSCOMM.VBX that is incompatible with Visual Basic 3.0 and caused an error to be
displayed during startup of the Configuration software. Version 1.01 solves this problem.
Additions: None
Version 1.02
TLE-INTL - International Module Release
TLE_PC.EXE 11/20/97
TLE_PC V1.02
BIOS V1.00
DSP V1.00
MCU V1.02
Changes: Corrected the Invalid Number Response in the Miscellaneous Screen to
match the operation of SIT + Audio.
Additions: Busy, Call Waiting, CAS Tone, Dial Tone, Reorder, Ringback, and
Test Tone screens were upgraded to allow for the addition of tone modulation, which is
used by some international configurations. An extra window above the frequency and
signal level settings allows for the setting of “Tones”, which includes the option of
Disabled, Single Tone, or Tone 1 +Tone 2 operation. The addition in the International
Module supports Tone 1 X Tone 2.
The SIT Screen was upgraded to SIT / Number Unobtainable Tone, which is used in
some International configurations. When Number Unobtainable Tone is selected, the
options under Miscellaneous, Invalid Number Response changes accordingly by
removing the SIT options and replacing them with the Number Unobtainable Tone
option.
The Miscellaneous Screen, Invalid Number Response, was upgraded to add SIT
Repeating, which is used in some international configurations.
The Call Waiting Screen - Country Code option was removed. Replacing the Country
Code option, the Cadence window was expanded to support a “delay between tone
bursts” in 5 mS increments and a Repeat option was added. This increased flexibility
should support all Call Waiting configurations.
