Teltone TLE-A - Caller ID and Call Waiting Features

Telephone Line Emulator User’s Manual
40-400-00020, Rev. M 74
FSK Timing Parameters
The following parameters are programmable in the TLE-ICID module:
Dual Tone to FSK
Line Reversal to Dual Tone
DTMF/FSK to Ring
Ring to DTMF/FSK
OSI to FSK
On-hook Channel Seizure
On-hook Mark Time
Off-hook Mark Time
Dual Tone Alerting Signal
Ring Burst Alerting Signal
See the following section for more details.
Programming
The programming of the TLE-ICID operating parameters is supported using multiple
screens. Call Waiting and Caller ID were once separate screens, but have been
combined in the TLE-ICID Software Module. The TLE-ICID Software Module allows a
user to program the Caller ID parameters for each line for greater flexibility. If only one
Caller ID Standard is chosen, then parameters not associated with that Standard will not
be able to be chosen. More advanced users have the option of choosing the Caller ID
Standard “Everything” and have no restrictions in accessing all programming parameters.
Note: The D
efaults button on each screen will reset the parameters for only the screen being
edited. If a user wishes to reset all parameters for a configuration to Defaults, then use
the D
efaults button on the Main TLE screen.
Caller ID and Call Waiting Modes
Figure 35. Caller ID/Call Waiting - Caller ID and Call Waiting Modes
