Teltone TLE-A - Details of Operation and Standards

Telephone Line Emulator User’s Manual
40-400-00020, Rev. M 64
Spain Defaults
To make the settings for this country available, follow the instructions in
“Importing Additional Countries” on page 41.
Description Frequency (Hz) Cadence *1 Signal level
Dial Tone 425 Continuous -20dBm to -5dBm
Special Dial Tone I 425 1.0(on)-0.1(off) -20dBm to -5dBm
Special Dial Tone II 425 0.32(on)-0.02(off) -20dBm to -5dBm
Ringing Tone I 425 1.5(on)-3.0(off) -37dBm to -5dBm
Ringing Tone II 425 1.5(on)-2.9(off) -37dBm to -5dBm
Ringing Tone III 425 1.5(on)-3.4(off) -37dBm to -5dBm
Ringing Signal I 25 1.5(on)-3.0(off) 65Vac +/- 90Vac
Ringing Signal II 25 1.5(on)-2.9(off) 65Vac +/- 90Vac
Ringing Signal III 25 1.5(on)-3.4(off) 65Vac +/- 90Vac
Busy Tone 425 0.2(on)-0.2(off) -35dBm to -5dBm
Reorder Tone 425 2x[0.2(on)-0.2(off)]-
0.2(on)-0.6(off)
-35dBm to -5dBm
SIT Tones 950 0.333(on) -32dBm to -12dBm
1400 0.333(on) -35.5dBm to-
13dBm
800 0.333(on)-1.0(off) -39dBm to -14dBm
N.U.T. 25 0.2(on)-0.2(off)-
0.2(on)-0.6(off)
-35dBm to -5dBm
Call Waiting Tone 425 0.6(on)-0.2(off)-
0.6(on)-1.0(off)
-15dBm to -6dBm
Metering Tones 12 000 [>0.05](on)-
[>0.05](off) 4.0V +/-
0.8V
Impedance: 600 Ω
