Teltone TLE-A - Page 121

Telephone Line Emulator User’s Manual
40-400-00020, Rev. M
115
UK Phone
Teltone TLE
2
3
4
5
RJ-11 Plug
(To UK Phone)
RJ-11 Plug
2345
RJ-11 Socket
245
UK
Network
Adapter
3
4
RJ-11 Plug
(To TLE)
B
470K
1.8 uF
250V
Adapter
Circuitry
Standard
RJ-11
Cable
(Twisted)
Shunt
B A
A
Figure 44. UK Phone Wiring Diagram
