Tenda i9 User Manual

17
Parameter
Description
Hardware Version
It specifies the hardware version number of the AP.
MAC Address
It specifies the physical address of the LAN port of the AP. If you connect the AP to
other devices using Ethernet cables, the AP uses this MAC address to communicate
with those devices.
IP Address
It specifies the IP address of the AP.
The web UI of the AP is accessible at this IP address. You can change the IP address
on the Network > LAN Setup page.
Subnet Mask
It specifies the subnet mask of the IP address of the AP.
Primary DNS Server
It specifies the primary DNS server of the AP.
Secondary DNS Server
It specifies the secondary DNS server of the AP.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
