Tenda i9 User Manual

72
8 SNMP
8.1 Overview
The Simple Network Management Protocol (SNMP) is the most widely used network management
protocol in TCP/IP networks. SNMP enables you to remotely manage all your network devices
compliant with this protocol, such as monitoring the network status, changing network device
settings, and receive network event alarms.
SNMP allows automatic management of devices from various vendors regardless of physical
differences among the devices.
8.1.1 SNMP management framework
The SNMP management framework consists of SNMP manager, SNMP agent, and
Management Information Base (MIB).
− SNMP manager: It is a system that controls and monitors network nodes using the SNMP
protocol. The SNMP manager most widely used in network environments is Network
Management System (NMS).An NMS can be a dedicated network management server, or
an application that implements management functions in a network device.
− SNMP agent: It is a software module in a managed device. The module is used to manage
data about the device and report the management data to an SNMP manager.
− MIB: It is a collection of managed objects. It defines a series of attributes of managed
objects, including names, access permissions, and data types of objects. Each SNMP agent
has its MIB. An SNMP manager can read and/or write objects in the MIB based on the
permissions assigned to the SNMP manager.
An SNMP manager manages SNMP agents in an SNMP network. The SNMP manager
exchanges management information with the SNMP agents using the SNMP protocol.
8.1.2 Basic SNMP operations
The AP allows the following basic SNMP operations:
− Get: An SNMP manager performs this operation to query the SNMP agent of the AP for
values of one or more objects.
− Set: An SNMP manager performs this operation to set values of one or more objects in
the MIB of the SNMP agent of the AP.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
