Tenda i9 User Manual

14
4.3 Configuring Client+AP mode
Configuration procedure:
Before configuration, ensure that the upstream AP is connected to the internet successfully.
Assume that the upstream AP has the basic information described in the following table.
IP Address
SSID
Security Mode
Security Key (Wireless Network Password)
192.168.0.254
Tenda_1
WPA2-PSK
87654321
Step 1 Log in to the web UI of this AP, and change its IP address to an unused IP address
belonging to the same network segment as that of the upstream AP, such as
192.168.0.253. For details, refer to Section 6.1 LAN Setup.
Step 2 Use the new IP address to log in to the web UI of this AP, and choose Quick Setup.
Step 3 Set the Working Mode to Client+AP.
Step 4 Click Scan.
Step 5 Select the SSID of the upstream AP from the detected SSIDs, which is Tenda_1 in this
example.
If the AP detects no wireless network, choose Wireless > Basic to enable the wireless function, and
then try again.
Step 6 After you select an SSID, the SSID, Security Mode, Encryption Algorithm, and Upstream AP
Channel are populated automatically. You just need to enter the password of the wireless
network of the upstream AP in the Key box. Set Key to the wireless network password of
the upstream AP, which is 87654321 in this example.
Step 7 Click Save.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
