Tenda i9 User Manual

77
9 Tools
9.1 Firmware Upgrade
This function upgrades the firmware of the AP for more functions and higher stability.
To prevent damaging the AP, verify that the new firmware version is applicable to the AP before
upgrading the firmware and keep the power supply of the AP connected during an upgrade.
Configuration procedure:
Step 1 Download the package of a later firmware version for the AP from http://www.tendacn.com
to your local computer, and decompress the package.
Step 2 Log in to the web UI of the AP and choose Tools > Firmware Upgrade.
Step 3 Click Choose File and select the file for upgrading the firmware.
Step 4 Click Upgrade.
--End
Wait until the progress bar is complete. Log in to the web UI of the AP again. Choose Status >
System Status and check whether the upgrade is successful based on Firmware Version.
After the firmware is upgraded, you are recommended to restore the factory settings of the AP and
configure the AP again, so as to ensure stability of the AP and proper operation of new functions.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
