Tenda i9 User Manual

65
7.6 Access Control
7.6.1 Overview
It specifies, based on MAC address filter rules, the wireless devices that can or cannot access the
wireless networks of the AP. Devices that have been controlled cannot connect to the
corresponding wireless network.
The AP supports the following MAC address filter rules:
− Disable: It indicates that access control is disabled.
− Allow: It indicates that only the wireless devices with the specified MAC addresses can
access the wireless networks of the AP.
− Disallow: It indicates that only the wireless devices with the specified MAC addresses
cannot access the wireless networks of the AP.
7.6.2 Configuring access control
Step 1 Choose Wireless > Access Control.
Step 2 From the SSID drop-down list box, select the SSID of the wireless network on which access
control must be implemented.
Step 3 Select an access control mode from the MAC Filter Mode drop-down list box.
Step 4 If you select Allow or Disallow, enter the MAC addresses to control in the access control
list and click Add.
If a wireless device to be controlled has been connected to the AP, you can click Add corresponding to
the device in the wireless client list to directly add it to the access control list.
Step 5 Click Save.
--End
Wireless access control list
Wireless client list

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
