Tenda i9 User Manual

64
Parameter
Description
Lock Power
It specifies whether the current transmit power settings of the AP can be
changed. If it is selected, the settings cannot be changed.
Preamble
It specifies whether to use long preamble or short preamble. A preamble is a
group of bits located at the beginning of a packet to enable a receiver of the
packet to perform synchronization and prepare for receiving data.
By default, the Long Preamble option is selected for compatibility with old
network adapters installed on wireless clients. To achieve better synchronization
performance of networks, you can select the Short Preamble option.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
