Tenda i9 User Manual

1
1 Getting to know your device
1.1 Overview
Tenda i9 is a wireless access point specially designed for offices, bars, coffee shops and other
indoor environments. Working at 2.4 GHz band, it provides a wireless transmission rate of as high
as 300 Mbps. Featured with 2 built-in high gain omni-directional MIMO antennas, i9 provides
powerful WiFi signal with strong wall penetration capacity and broad WiFi coverage. Compliant
with IEEE 802.3af standard, i9 allows you to apply long-distance power supply via PoE without
changing your original power network. All of this makes i9 an ideal choice for WiFi coverage.
1.2 Appearance
1.2.1 LED indicator
LED Indicator
Status
Description
System indicator
Solid on
The system is starting or faulty.
Blinking
The system is working properly.
Off
The system is powered off or the LED indicator is turned off.
System indicator

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
