Tenda i9 User Manual

60

ACK Policies
WMM specifies the Normal ACK and No ACK policies.
− According to the No ACK policy, no ACK packet is used during wireless packet transmission
to acknowledge packet reception. This policy is applicable to scenarios where interference
is mild and can effectively improve transmission efficiency. In case of strong interference,
lost packets are not sent again if this policy is adopted. This leads a higher packet loss rate
and reduces the overall performance.
− According to the Normal ACK policy, each time a receiver receives a packet, it sends back
an ACK packet to acknowledge packet reception.
7.4.2 Changing the WMM settings
By default, the WMM function of the AP is enabled and the Optimized For Capacity mode is
adopted. Procedure for changing the WMM settings:
Step 1 Choose Wireless > WMM Setup.
Step 2 Set the WMM to Enable.
Step 3 Select the required WMM optimization mode.
Step 4 If you select Custom, set the WMM parameters as required.
Step 5 Click Save.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
