Tenda i9 User Manual

18
5.2 Wireless Status
To view the radio status and SSID status of the wireless network, choose Status > Wireless Status.
Parameter description
Parameter
Description
RF Status
RF (On/Off)
It specifies whether the wireless function of the AP is enabled.
Network Mode
It specifies the current network mode of the AP.
Channel
It specifies the current working channel of the AP.
SSID Status
SSID
It specifies the names of all the wireless networks of the AP.
MAC Address
It specifies the physical addresses corresponding to the SSIDs of the
AP.
Enable/Disable
It specifies whether the wireless networks corresponding to the
SSIDs of the AP are enabled.
Security Mode
It specifies the security modes of the wireless networks
corresponding to the SSIDs of the AP.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
