Tenda i9 User Manual

55
7.2 RF Settings
7.2.1 Overview
The RF module is used to set radio parameters of the AP. The following briefly describes the SSID
isolation function.
Isolate SSID
This function isolates the wireless clients connected to different wireless networks of the AP. For
example, if user 1 connects to the wireless network corresponding to SSID1, whereas user 2
connects to the wireless network corresponding to SSID2, the two users cannot communicate with
each other after SSID isolation is implemented.
7.2.2 Changing the RF settings
Step 1 Choose Wireless > RF.
Step 2 Change the parameters as required. Generally, you only need to change the Enable RF,
Channel, Lock Channel, Isolate SSID and Client Timeout Interval settings.
Step 3 Click Save.
Disable Isolate SSID
SSID1
SSID2
Devices connect to
SSID1 and SSID2 can
communicate with
each other
Enable Isolate SSID
×
SSID2
SSID1
Devices connect to
SSID1 and SSID2
cannot communicate
with each other

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
