Tenda i9 User Manual

26
Parameter description
Parameter
Description
DHCP Server
It specifies whether to enable the DHCP server function. To enable it, select the check
box. To disable it, deselect the check box. By default, it is disabled.
Start IP Address
It specifies the first IP address that can be assigned by the DHCP server to a client. The
default value is 192.168.0.100.
End IP Address
It specifies the last IP address that can be assigned by the DHCP server to a client. The
default value is 192.168.0.200.
Lease Time
It specifies the validity period of an IP address assigned by the DHCP server to a client.
The default value is 1 day.
Subnet Mask
It specifies the subnet mask assigned by the DHCP server to clients. The default value
is 255.255.255.0.
Gateway
It specifies the gateway IP address assigned by the DHCP server to clients. The default
value is 192.168.0.1.
When a client accesses a server or host located outside the network segment
where the client resides, the data from and to the client must be forwarded by
the gateway. Generally, the IP address of the gateway is the LAN IP address of
the router in your LAN.
Primary DNS Server
It specifies the primary DNS server IP address assigned by the DHCP server to clients.
The default value is 8.8.8.8.
To enable clients to access web pages using domain names, set this parameter
to a correct DNS server IP address or DNS proxy IP address.
Secondary DNS
Server
It specifies the secondary DNS server IP address assigned by the DHCP server to
clients. This IP address is optional.
If another DHCP server is available in your LAN, ensure that the IP address pool of the AP does not
overlap the IP address pool of that DHCP server. Otherwise, IP address conflict may occur.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
