Tenda i9 User Manual

34
Parameter
Description

TKIP: It indicates the Temporal Key Integrity Protocol. If TKIP is used, the maximum
wireless throughput of the AP is limited to 54 Mbps.

TKIP&AES: It indicates that both TKIP and AES encryption algorithms are supported.
Wireless clients can connect to the wireless network corresponding to the selected
SSID using TKIP or AES.
Key
It specifies a pre-shared WPA key. A WPA key can contain 8 to 63 ASCII characters or
8 to 64 hexadecimal characters.
Key Update Interval
It specifies the automatic update interval of a WPA key for data encryption. A shorter
interval results in higher data security.
The value 0 indicates that a WAP key is not updated.

WPA and WPA2
Parameter description
Parameter
Description
Security Mode
The WPA and WPA2 options are available for network protection with a RADIUS server.

WPA: It indicates that the wireless network corresponding to the selected SSID is
encrypted using WPA.

WPA: It indicates that the wireless network corresponding to the selected SSID is
encrypted using WPA.
RADIUS Server IP
It specifies the IP address of the RADIUS server for client authentication.
RADIUS Port
It specifies the port number of the RADIUS server for client authentication.
RADIUS Password
It specifies the shared password of the RADIUS server.
Encryption
Algorithm
It specifies the encryption algorithm corresponding to the selected security mode. The
available options include AES, TKIP, and TKIP&AES.

AES: It indicates the Advanced Encryption Standard.

TKIP: It indicates the Temporal Key Integrity Protocol.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
