Tenda i9 User Manual

33
Parameter
Description
wireless network corresponding to the selected SSID only with the password specified
by Key 2.
ASCII
It indicates that a key selected for the Open or Shared authentication type contains
hexadecimal characters.
5 or 13 ASCII characters are allowed in the key.
Hex
It indicates that a key selected for the Open or Shared authentication type contains
hexadecimal characters.
10 or 26 hexadecimal characters (range: 0-9, a-f, and A-F) are allowed in the key.
RADIUS Server IP
These parameters are dedicated to the 802.1x authentication type.
It specifies the IP address/port number/shared key of the RADIUS server for
authentication.
RADIUS Port
RADIUS Password

WPA-PSK, WPA2-PSK, and Mixed WPA/WPA2-PSK
Parameter description
Parameter
Description
Security Mode
It indicates the personal or pre-shared key security mode, including WPA-PSK,
WPA2-PSK, and Mixed WPA/WPA2-PSK.

WPA-PSK: It indicates that the wireless network corresponding to the selected SSID
is encrypted using WPA-PSK.

WPA2-PSK: It indicates that the wireless network corresponding to the selected
SSID is encrypted using WPA2-PSK.

Mixed WPA/WPA2-PSK: It indicates that wireless clients can connect to the
wireless network corresponding to the selected SSID using either WPA-PSK or
WPA2-PSK.
Encryption Algorithm
It specifies the encryption algorithm corresponding to the selected security mode. If
Security Mode is set to WPA-PSK, this parameter has the AES and TKIP values. If
Security Mode is set to WPA2-PSK or Mixed WPA/WPA2-PSK, this parameter has the
AES, TKIP, and TKIP&AES values.

AES: It indicates the Advanced Encryption Standard.

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
